Tube Feeders Inc.

Reject Parts Conveyor for Siemens


Specifications

Applicable Siemens Models: All models with S-FEEDER Interface. Adapter available from Siemens for use on X-Table.
Maximum Component Width: 44.5mm (1-3/4")
Belt Travel Speed: 63.5mm (2-1/2 inches) per second minimum
Operator Interface: Belt Run (push button)
                              Reset (push button)
                              Visible Alarm (red led) – Component on belt
                              Audible Alarm – Belt full
                              Run Length – Rotary switch
Mounting: Dowel/Pin locating and magnetic hold down
Electrical Connection: RPC cable plugs into S-Table power port
