Applicable Zevatech Models: FS - 730, FM – 740, FS – 750, FM – 760, ASM                                               810
Applicable JUKI Models: All KE - 20xx machines, KE - 750, KE - 760
Feeder Slots Required: One 17mm slot (SIF III)
Refresh Time: Approximately 1/2 second
Maximum Component Length for SIF III: 10mm
Maximum Component Length for SIF III-L: 20mm
Mounting Width for SIF III: 15.8mm
Mounting Width for SIF III-L: 20.6mm
Maximum Tube Width for SIF III: 10.3mm
Maximum Tube Width for SIF III-L: 16mm
Operator Interface: Load push button
Mounting: Spring loaded clamp onto feeder mount, front and bottom location pins
Compressed Air Connection: Quick disconnect plugs into Juki air port.
                                              Multi-feeder manifold available
Electrical Connection: 12 pin connector plugs into host machine
